Suspended Cubicles
Suspended

Description

Marathon Suspended has specially engineered design flexibility that enables it to be installed in almost any project. With a load bearing head beam the system is designed for high use washroom and changing areas in demanding public environments and can incorporate both the Classic and Conform systems.

Key Benefits

  • Option of a fully suspended System supported by connections to structural slab or walls above suspended ceiling
  • The extruded aluminium hollow head section is capable of spans up to 6 metres of single depth wall mounted cubicles
  • Vertical posts are mechanically joined to the head beam with screwport and through bolt connections to form a structural framework including capped ends
  • Full length channels are used to attach partition and pilaster to walls
  • Engineered to be used in double or single island configuration or wall mounted
  • Marathon suspended can be used in free standing block, between walls or with wall mounted supports concealed within the ceiling void
  • Design flexibility enables it to be installed in almost any project, even with large ceiling voids, unlike traditional ceiling hung systems

Specification
Product Card

Specification Product Card

Technical
Content DWG

Technical Content DWG

Technical
Content PDF

Technical Content PDF

Color
Chart

Color Chart

All
Files

All Files

Suspended
